Atchison, Topeka & Santa Fe 2900 4-8-4 Tender Truck Drawings

Atchison, Topeka & Santa Fe 2900 4-8-4 Tender Truck Drawings

Atchison, Topeka & Santa Fe Railroad

Name DWG. Number Drawing Title DWG. Size (in) Scale to 1 ft. Wheel Arrangement Price Qty Add To Cart
Atchison, Topeka & Santa Fe 2900 4-8-4 Tender Truck Drawings- Locking Block, 6 1/2” x 12” A-5887 Locking Block, 6 1/2” x 12” 13x8 Full 4-8-4
1
$0.43
Atchison, Topeka & Santa Fe 2900 4-8-4 Tender Truck Drawings- Locking Block Bolt A-5888 Locking Block Bolt 13x8 Full 4-8-4
1
$0.43
Atchison, Topeka & Santa Fe 2900 4-8-4 Tender Truck Drawings- Snubber Spring Fuller Block A-5889 Snubber Spring Fuller Block 13x8 6” 4-8-4
1
$0.43
Atchison, Topeka & Santa Fe 2900 4-8-4 Tender Truck Drawings- Buckeye Eight Wheel Truck – Arrangement (AT&SF) E-5890 Buckeye Eight Wheel Truck – Arrangement (AT&SF) 34x44 2” 4-8-4
1
$6.23
Atchison, Topeka & Santa Fe 2900 4-8-4 Tender Truck Drawings- Center Bolster E-5891 Center Bolster 34x40 3” 4-8-4
1
$5.67
Atchison, Topeka & Santa Fe 2900 4-8-4 Tender Truck Drawings- Transverse Bolster D-5892 Transverse Bolster 34x20 3” 4-8-4
1
$2.83
Atchison, Topeka & Santa Fe 2900 4-8-4 Tender Truck Drawings- Side Frame – End E-5893 Side Frame – End 34x40 3” 4-8-4
1
$5.67
Atchison, Topeka & Santa Fe 2900 4-8-4 Tender Truck Drawings- Side Frame – Intermediate D-5894 Side Frame – Intermediate 34x20 3” 4-8-4
1
$2.83
Atchison, Topeka & Santa Fe 2900 4-8-4 Tender Truck Drawings- Equalizer D-5895 Equalizer 34x20 3” 4-8-4
1
$2.83
Atchison, Topeka & Santa Fe 2900 4-8-4 Tender Truck Drawings- Spring Seat, Brake Hanger Bracket D-5896 Spring Seat, Brake Hanger Bracket 34x20 4” 4-8-4
1
$2.83
Atchison, Topeka & Santa Fe 2900 4-8-4 Tender Truck Drawings- Air Cylinder Support Brackets D-5897 Air Cylinder Support Brackets 34x20 6” 4-8-4
1
$2.83
